NOZZLE PERFORMANCE CHART #6
SMITHCO NOZZLE PERFORMANCE CHART #1
Nozzle Type: Raindrop 1/4"
Spacing: 20 inch (51cm)
Calibration: Liters Per Hectare
Pressure
Nozzle
Capacity
Application Rate LPH
Speed KPH (MPH)
Color Size psi (bar) (L/Min) 3 (2) 5 (3) 6 (4) 8 (5)
Grey RA-2 20 (1.4) 0.53 196 131 98 79
30 (2.1) 0.64 243 159 122 96
40 (2.9) 0.76 279 185 139 111
50 (3.6) 0.83 310 208 155 124
Yellow RA-4 20 (1.4) 1.06 393 261 196 157
30 (2.1) 1.32 486 319 243 187
40 (2.9) 1.51 561 374 280 224
50 (3.6) 1.70 617 411 308 252
Dk Blue RA-5 20 (1.4) 1.36 486 327 243 196
30 (2.1) 1.66 598 392 299 243
40 (2.9) 1.89 691 467 345 280
50 (3.6) 2.12 785 523 392 308
Green RA-6 20 (1.4) 1.63 598 392 299 233
30 (2.1) 1.97 729 486 364 289
40 (2.9) 2.27 841 561 420 336
50 (3.6) 2.53 935 617 467 374
Red RA-8 20 (1.4) 2.15 785 523 392 317
30 (2.1) 2.65 953 635 476 383
40 (2.9) 3.02 1103 748 551 440
50 (3.6) 3.40 1234 822 617 495
Tan RA-10 20 (1.4) 2.68 991 654 495 392
30 (2.1) 3.29 1196 804 598 476
40 (2.9) 3.78 1383 935 691 551
50 (3.6) 4.16 1552 1028 776 617
Lt Blue RA-15 20 (1.4) 4.16 1477 991 738 589
30 (2.1) 4.91 1795 1196 897 719
40 (2.9) 5.70 2075 1383 1037 832
50 (3.6) 6.43 2337 1552 1168 935
