NOZZLE PERFORMANCE CHART #8
SMITHCO NOZZLE PERFORMANCE CHART #1
Nozzle Type: Turbo Floodjet
Spacing: 30 inch (76cm)
Calibration: Liters Per Hectare
Pressure
Nozzle
Capacity
Application Rate LPH
Speed KPH (MPH)
Color Size psi (bar) (L/Min) 5 (3) 6 (4) 8 (5) 6 (10)
Red TF-VS2 20 (1.4) 1.06 178 131 103 84.2
30 (2.1) 1.32 215 159 131 103
Brown TF-VS2.5 20 (1.4) 1.32 219 165 131 109
30 (2.1) 1.63 267 200 161 134
Gray TF-VS3 20 (1.4) 1.59 262 196 157 131
30 (2.1) 1.97 322 241 196 161
White TF-VS4 20 (1.4) 2.16 350 262 206 175
30 (2.1) 2.61 430 322 262 215
Blue TF-VS5 20 (1.4) 2.69 430 327 262 215
30 (2.1) 3.29 524 411 327 262
Green TF-VS7.5 20 (1.4) 4.16 655 486 402 327
30 (2.1) 4.92 804 598 486 402
Black TF-VS10 20 (1.4) 5.30 879 655 524 439
30 (2.1) 6.43 1066 804 636 533
