Smithco 1004 - Nozzle Performance Chart #7

30
Nozzle Charts
NOZZLE PERFORMANCE CHART #7
SMITHCO NOZZLE PERFORMANCE CHART #1
Nozzle Type: Turbo Floodjet
Spacing: 30 inch (76cm)
Calibration: US Gal/Acre (GPA) & US Gal/1,000 Square Feet (GPT)
Pressure
Nozzle
Capacity
Application Rate GPA
Speed MPH (KPH)
Application Rate GPT
Speed MPH (KPH)
Color Size psi (Gal/Min)3 (5)4 (6)5 (8)6 (10)3 (5)4 (6)5 (8)6 (10)
Red TF-VS2 20 (1.4) 0.28 19 14 11 9 0.40 0.30 0.25 0.20
30 (2.1) 0.35 23 17 14 11 0.50 0.40 0.30 0.25
Brown TF-VS2.5 20 (1.4) 0.35 23.4 17.6 14 11.7 0.54 0.40 0.32 0.27
30 (2.1) 0.43 28.6 21.4 17.2 14.3 0.66 0.49 0.40 0.33
Gray TF-VS3 20 (1.4) 0.42 28 21 16.8 14 0.64 0.48 0.39 0.32
30 (2.1) 0.52 34.4 25.8 21 17.2 0.79 0.59 0.48 0.40
White TF-VS4 20 (1.4) 0.57 37.4 28 22 18.7 0.86 0.64 0.51 0.43
30 (2.1) 0.69 46 34.4 28 23 1.06 0.79 0.64 0.53
Blue TF-VS5 20 (1.4) 0.71 46 35 28 23 1.06 0.80 0.64 0.53
30 (2.1) 0.87 56 44 35 28 1.29 1.01 0.80 0.64
Green TF-VS7.5 20 (1.4) 1.10 70 52 43 35 1.61 1.20 1.00 0.80
30 (2.1) 1.30 86 64 52 43 2.00 1.47 1.25 1.00
Black TF-VS10 20 (1.4) 1.40 94 70 56 47 2.20 1.70 1.60 1.10
30 (2.1) 1.70 114 86 68 57 2.62 1.98 1.56 1.31
