Smittybilt XRC 2 User Manual

13
Winch Parts List
Ref SB part# QTY Description
1
97202-01
1 XRC2 Motor
2
97202-02
1 Stationary Gear Housing Assembly
3
97202-03
1 T-Series Carrier Assembly
4
97202-04
1 T-Series Rotator Gear
5
97202-05
1 Drum Support Plate
6
97202-06
4 Pan Head Screw
7
97202-07
1 Drum Support Bushing
8
97202-08
1 Clutch Assembly
9
97202-09
1 Spring
10
97202-10
1 Drum Assembly
11
97202-11
1 Screw
12
97202-12
1 T-Series Bushing
13
97202-13
1 Thick Flat Washer
14
97202-14
2 Hex Flange Nut
15
97202-15
1 T-Series Base plate Assembly
16
97202-16
1 Tension Plate
17
97202-17
1 T-Series F/W Knob Assembly
18
97202-18
1 Elastic Pin
19
97202-19
2 Hex Socket Screw
20
97202-20
2 Screw
21
97202-21
2 Screw
22
97202-22
2 Flat Washer
23
97202-23
2 Lock Washer
24
97202-24
2 Nut
25
97202-25
1 Red Strap
26
97202-50
1 Switch Assembly (Remote)
27
97202-32
1 Cable Assembly
