XRC 10 WINCH PARTS LIST
No.
Parts No. Description Qty No. Part No. Description Qty
01 97210-01 Gear Box End Cover 1 17 97210-17 Remote Control 1
02 97210-02 Gasket 1 18 97210-18 Control Box Assy 1
03 97210-03 Bearing 1 19 97210-19 Nylon Bearing 2
04 97210-04 Sun Gear-Input 1 20 97210-22 Tie Rod 2
05 97210-05 Inner Gear 1 21 97210-21 Drum 1
06 97210-06 Gasket 2 22 97210-22 Brake System 1
07 97210-07 Gear Carrier-Input 1 23 97210-23 Coupling Joint 1
08 97210-08 Gear Carrier-Intermediate 1 24 97210-24 Winch Mount Bolt 4
09 97210-09 Washer-1.2mm thickness 2 25 97210-25 Motor Base 1
10 97210-10 Clutch Gear 1 26 97210-26 Rotor 1
11 97210-11 Gear Carrier-Output 1 27 97210-27 Stator 1
12 97210-12 Gear Box Tube 1 28 97210-28 Carbon Frame & Brush Assy 1
13 97210-13 Clutch Handle Assy 1 29 97210-29 Motor End Cover 1
14 97210-05 Outer Spline 1 30 97210-30 Roller Fairlead 4
15 97210-15 Tie Rod Bolt 4 31 97210-31 Clevis Hook 1
16 97210-16 Gear Box Base 1 32 97210-32 Wire Rope 1
