Installation Manual
XRC 15 WINCH PARTS LIST
No.
Parts No.
Description Qty
No.
Part No. Description Qty
01 97215-01 Sun Gear - Output 1 26 97215-26 Gasket 2
02 97215-02 Gear Carrier Assy - Output 1 27 97215-27 Inner Gear 1
03 97215-03 Gear Carrier Assy - Intermediate
1 28 97215-28 Clutch Gear 1
04 97215-04 Washer 1 29 97215-29 Gear Box Tube 1
05 97215-05 Planet Gears - Output 1 30 97215-30 Gear Box Graft Stan 1
07 97215-07 Washer 1 32 97212-32 Gear Box End Cover 1
08 97215-08 Drum Assy 1 33a 97215-33a Washer 4 20
09 97215-09 Bolt for Brake 1 33b 97215-33b
Bolt M4*25 20
10 97215-10 Brake Assy 1 36 97215-36 Bearing 1
11 97215-11 fixing sleeve 1 37a 97215-37a Shaft Sleeve 1
12 97215-12 Rotor (12V) 1 37b 97215-37b
Washer 1
13 97215-13 Bolt M5*20 4 37c 97215-37c Clutch 1
14 97212-14 Washer 18 2 37d 97215-37d
Clutch Bolt 1
15 97215-15 Tie Rod Bolt 6 37e 97215-37e Clutch Spring 1
16 97215-16 Motor End Cover 1 39 97215-39 Bolt 8
17 97215-17 4.5”Carbon Assy 1 41 97215-41 Wire Rope 1
18 97215-18 Stator (12V) 1 42 97215-42 Wire Rope Mount Bolt M6*8
1
19 97215-19 Long Bolt 1 43 97215-43 Bolt M12*40 8
20 97215-20 Motor Base 1 44 97215-44 Washer 12 10
21 97215-21 Nylon Bearing 2 46 97215-46 Clevis Hook 1
22 97215-22 Tie Rod 2 47 97215-47 Roller Fairlead 1
23 97215-23 Bolt M5*20 10 48 97215-48 Bolt M12*25 2
24 97215-24 Washer 5 2 49 97215-49 Control Box Assy (12V) 1
25 97215-25 Gear Box Base 1 53 97215-50 Remote Control 1
