4 CONNECTIONS (rear panel)
!
!
4.1 Mains Power
The ACTIVE-1 includes a 9V mains power supply. The power LED on the front
panel (to the left of the volume knob) will illuminate when the external power
supply is connected and mains power is present. Please ensure the correct
power supply is used with the ACTIVE1 and that the power rating on the
provided power supply suites your AC power outlet. Please make sure your
Mains voltage is compatible with the provided adaptor.
!
!
!
4.2 Sources (Inputs)
!
Sources is the description of the 4 INPUT connectors.
•
Source A is the stereo RCA inputs
•
Sources B and C are the 6.5mm or ¼ inch stereo input jacks
•
Source D is the USB input. The USB input has a built in Legacy compatible driver for simple
plug & play operation. The USB input does not need mains power to operate. An ASIO
driver is also available for download from our website.
!
!
!
!
!
!
!
