ENV PATCH POINTS

This is an input which initialises the ENV cycle (eg: the gate output from a keyboard/controller with a minimum

output of 1 volt).

This is the trig/retrig input. A short positive pulse will re-initialise the already gated ENV.

This is the output voltage of the ENV which can be used to control any voltage controlled input.
