4
Guide for Enclosure
Before You Start
Get the Tools Ready Useful tips for assembling
You don’t need to tighten all the screws until the last step, so that you
can adjust every interface to be perfectly matched.
Please tear off the membranes on the plates before you assemble them.
Used Symbols
Tips
Notice
Make sure that the highlighted part is facing the right way.
Details you should be aware of
throughout the process.
Tips offer you convenient
operations and additional options.
2.5mm Hex Key Wrench
for M4 Screws
2.0mm Hex Key Wrench
for M3 Screws
Spanner
for M4 Locknuts
After Assembling
All the Parts
To Next Page
