11
Assembly
Read and follow the assembly and adjustment
instructions for your mower.
All fasteners are in the parts bag. Do not discard
any parts or material until the unit is assembled.
NOTE: In this instruction book, left and right describe the
location of a part with the operator on the seat.
Parts Bag - Contents
The fasteners and other loose parts are shown below. The quantity
is shown in brackets ( ).
Figure 2. Parts Bag Components
A. 5/16 Nylock Flange Nut (Qty: 4)
A
WARNING
Before doing any assembly or maintenance to the
mower, remove the wires from the spark plugs.
