Section 1 – FAMILIARIZATION – DECALS / SYMBOLS
BLADE ENGAGED
POSITION
BLADE DISENGAGED POSITION
ENGINE SPEED CONTROL SYMBOLS
BLADE LEVER
POSITION
SYMBOLS
RABBIT
“FAST”
TURTLE
“SLOW”
CHOKE
POSITION
ENGINE
SPEED
CONTROL
AUTOMATIC BLADE
STOP DECAL - 24072
CLUTCH/BRAKE
DECAL - 2-8514
TRACTION
CLUTCH
PARK
BRAKE
E
N
G
I
N
E
SAFETY INSTRUCTION
35974
TRANSMISSION SHIFT
LEVER SYMBOLS
FAST
SLOW
NEUTRAL
REVERSE
MACHINE FRONT
MACHINE REAR
CLUTCH/BRAKE,
PARKING BRAKE,
BLADE OPERATION
PARKING
BRAKE
SYMBOL
