20
Regular Maintenance
Figure 13. Transmission ID Tag Location
A. ID Tag
TUFF TORQ K46Z
1001010101010010101
Transmission Identification
To determine what transmission is in your tractor, check
the identification tag attached to the axle of the
transmission (Figure 13), or check your tractor’s parts
book.
Transmission Maintenance
The K46 transmission is a sealed unit and does not
require regular maintenance. If the transmission lacks
drive or is excessively noisy, it may need to be purged.
See dealer for service.
A
Hood Removal and Installation
HOOD REMOVAL
1. Open the hood.
2. Remove the socket and bulbs (A, Figure 14) by
twisting the socket counterclockwise and pulling it out
of the bezel (B). Repeat on other side.
3. Rock the hood back slightly and lift hood (B, Figure
16) off pivot posts (C). Set hood on a clean and flat
surface.
HOOD INSTALLATION
1. Set hinge posts (A, Figure 15) onto pivot posts (C).
2. Roll the hood forward until it reaches the stops (D).
3. Install the socket and bulb (A) by pushing it into the
bezel (B) twisting the socket and bulb clockwise.
Repeat on other side.
4. Close the hood.
Figure 15. Hood Removal and Installation
A. Hinge Post
B. Hood
C. Pivot Post
D. Stop
A
C
B
Figure 14. Head Light
A. Socket and Bulb
B. Bezel
A
B
A
D
