9
ITEM NO.
QTY.
PART #
DESCRIPTION
1 5 27192 LUG NUT 1/2-20, YZ
2 1 29617 FLW, .77 X 1.31 X .06 YZ
3 2 35602 BEARING 30MM X 62MM
4 1 58642 ASSY., COUPLING W/ LUBE FITTING*
5 1 58650 ASSEMBLY, PLATE/SEAL
6 1 72960 REAR WHEEL HUB
7 1 72965 CVT AXLE SUPPORT
8 1 72975 AXLE, CVT
9 1 90297 COTTER PIN,1/8 X 3/4 YZ
10 4 91299 HNYL,3/8-16, YZ
11 1 91778 WOODRUFF KEY 808
12 4 92052 HHCS, 3/8-16 X 5.5 - YZ
13 1 92038 HEX NUT, 7/8-14, YZ
14 2 92045 SNAP RING, 30MM, HD
15 2 92046 FLAT WASHER, 1 3/16 X 1 5/8 X .06
AXLE GROUP
*NOTE: Lube fitting part number is 13864.
GROUNDS CRUISER UTILITY VEHICLE SERIES 0 MANUAL No. 06126
