English (Original instructions)
EN
AR BG CS DA DE ES ET FI FR HR HU IT LT LV NL NO PL PT RO RU SK SL SR SV TR UK
SPECIFICATIONS
Model ESXDHT82
Voltage 82 volts
No load speed 4000 (±10%) SPM
Blade speed 4000 (±10%) SPM
Blade length 66 cm
Cutting capacity 33 mm
Measuered sound
pressure level
85 dB (A), k=3.0
Guaranteed
sound power level
96 dB(A)
Vibration level
<2.5 m/s
²
, k=1.5 m/s
²
Weight without
battery pack
4.48 kg
DESCRIPTION
See Figure 1.
1. Blade cover
2. Blade
3. Guard
4. Micro switch
5. Front handle
6. Rotate release
7. Trigger switch
8. Safety lock button
9. On/off power button
10. Anti-jamming button
ASSEMBLY
UNPACKING
This product requires no assembly.
Carefully remove the product and any
accessories from the box. Make sure
that all items listed in the packing list are
included.
Inspect the product carefully to make sure
no breakage or damage occurred during
shipping.
Do not discard the packing material
until you have carefully inspected and
satisfactorily operated the product.
PACKING LIST
Hedge trimmer
Operator's manual
OPERATION
For complete charging instructions, refer to
the Operator’s Manuals for your battery pack
and charger models.
NOTE: To avoid serious personal injury,
always remove the battery pack and keep
hands clear of the lock-out button when
carrying or transporting the tool.
INSTALL BATTERY PACK
Place the battery pack in the hedge
trimmer. Align groove in battery pack with
raised rib on hedge trimmer. See figure 2.
Make sure the latch on the hedge trimmer
snaps in place and that battery pack is
secured in hedge trimmer before beginning
operation.
REMOVE BATTERY PACK
Locate the latch on the hedge trimmer and
depress to release the battery pack from
the hedge trimmer. See Figure 2.
Remove battery pack from the hedge
trimmer.
