Snapper XD SXDWM82

35
PARTS LIST
ITEM NO. PART NO. DESCRIPTION QTY
1 770168 KIT, UPPER HANDLE, NA
1
2 ----- SPONGE 1
3 ----- PUSH ROD, UP 1
4 770170 KIT, STOP 1
5 ----- SPONGE 1
6 ----- PIECE, LIMIT 1
7 770169 KIT, LEVER 1
11 770171 KIT, CABLE ASSEMBLY 1
12 ----- LASSO, THE START 1
13 ----- SLIDER 1
14 ----- SEAT, FIXED 1
15 -----
SPRING 1
16 770173 KIT, BUTTON 1
17 ----- BUTTON, THE START 1
18 ----- SPRING 1
19 -----
GASKET 1
20 ----- SCREW 1
21 770172 KIT, SWITCH BOX COMPONENT, NA 1
22
----- COVER, DOWN
1
23
----- SLIDER, SWITCH
1
24
----- SPRING
1
25
-----
SWITCH 1
26
----- BOARD, RIGID
1
27
----- COVER, UP
1
29
----- SCREW
2
30
----- SHAFT, SMALL
1
31
----- BOARD, LINE PRESSING
1
32
----- SCREW
2
33
----- SCREW
2
34
----- WIRE
1
11
770171 KIT, CABLE ASSEMBLY
1
16
770173 KIT, BUTTON
1
36 770182
KIT, GRASS BAGGER
1
173
----- BAG, CLOTH
1
174
----- FRAME, GRASS BAG
1
