SERVICE SCHEDULE
ITEM SERVICE PERFORMED REF. EACH
USE
5
HRS
25
HRS
50
HRS
100
HRS
EACH
SEASON
Engine Oil
Check Oil Level Page 10
X
Initial Oil Change Page 14
X
Periodic Oil Change Page 14-15
X*
Air Pre-Cleaner
Clean Sponge Element Engine Manual
X**
Air Cleaner
Clean or Replace Engine Manual
X**
Spark Plug
Replace Engine Manual
X
Fuel Filter
Replace Page 17
X
Engine Cooling
System
Clean Shroud & Fins Engine Manual
& Page 16
X**
Battery
Check Electrolyte Page 21 & 22
XX
Charge Battery Page 21
X
Testing Battery Page 22
X
Tires
Check Pressures Page 10
XXX
Drive Belts
Check For Wear And
Tension
Page 15
XX
Mower Blades
Check For Wear, Damage
& Replacement
Page 20
X
Mower Deck
Clean Debris
Accumulation
Page 15
X
Mower Deck
Clean Outside and
Underside
Page 15
X
Lubrication
Points
Grease or Oil Pages 15-16
XX
Hydrostatic
Trans. Oil
Check Oil Level Page 16
XX
Hydrostatic
Trans. Filter
Replace Filter Page 16 First Change at 200 Hours.
Thereafter every 500 Hours.
* Change oil every 25 hours when operating under heavy load or high temperatures.
**Clean more often under dusty conditions or when air debris is present
MAINTENANCE PARTS
4.8.1. MAINTENANCE/REPLACEMENT PARTS
MAINTENANCE PARTS
Mower Blades (52” Deck, Standard Lift) 2-9246
Mower Blades (52” Deck, Low Lift) 7-3395
Mower Deck Belt (52” Deck) 4-2776
Mower Blades (61” Deck, Standard Lift) 2-9251
Mower Blades (61” Deck, Low Lift) 7-3396
Mower Deck Belt (61” Deck) 3-5542
Upper Drive Shaft To Hydro Pump Belt 3-5544 (2)
Deck Drive Shaft To Electric Clutch -Belt 3-5543 (2)
Battery 3-5610
