SUPER CLASS-D SERIES AMPLIFIER
2 Owner’s Manual / Installation Guide
INTRODUCTION
Amplifiers provide high-performance sound reinforcement for your mobile audio equipment. Its versatility enables
compatibility with optional Equalizers, Frequency Dividing Network Crossovers, and other audio processors in a
customized system. The Multi-Mode bridging capabilities allow flexibility in hosting several different speaker
configurations.
To achieve optimum performance, it is highly recommended that you read this Owners Manual before beginning
installation.
FEATURES
GOLD COLOR SPEAKER AND POWER SUPPLY CONNECTORS.
ANJUSTABLE INPUT SENSITIVITY.
SHORT CIRCUIT / THERMAL / OVERLOAD / DC PROTECTION.
SUB-WOOFER VARIABLE LOW PASS FILTER & HIGH PASS FILTER.
2-OHM STABLE (4-Ohms Bridged).
SOFT DELAYED REMOTE TURN-ON.
HIGH / LOW LEVEL INPUTS.
FLOATING GROUND INPUTS.
MONO BRIDGEABLE.
MOSFER SWITCHING POWER SUPPLY.
PHANTOM CHANNEL FOR POWERING CENTER SPEAKER OR SUBWOOFER.
CHASSIS MOUNTED FUSE.
BASS BOOST.
HIGH EFFICIENCY.
WARNING
High powered audio systems in a vehicle are capable of generating “Live Concert” high levels of sound pressure.
Continued exposure to excessively high volume sound levels may cause hearing loss or damage. Also, operation of
a motor vehicle while listening to audio equipment at high volume levels may impair your ability to hear external
sounds such as: horns, warning signals, or emergency vehicles, thus constituting to a potential traffic hazard. In the
interest of safety, Consumer Electronics recommends listening at lower volume levels while driving.
PLANNING YOUR SYSTEM
Before beginning the installation, consider the following:
a) If you plan to expand your system by adding other components sometime in the future, ensure adequate space
is left, and cooling requirements are met.
b) Should you use high or low level inputs?
Your Amplifier has been designed to accept either High-Level (speaker outputs from your radio) or Low-Level
(Pre-Amp outputs from your radio) signal source.
If you radio / source is equipped with Pre-Amp outputs, it is possible to utilize them to drive the Amplifier and
connecting (Amplifier) to the 2 rear speakers.
Then, use the built-in power of your radio to drive the 2 front speakers.
NOTE : DISTORTION LEVEL IS CONSIDERABLY LOWER FROM PRE-AMP (LOW LEVEL) OUTPUTS, THAN SPEAKER (HIGH LENEL) OUTPUTS.
