Snom M110 SC Bundle - Page 3

3
Wall mounting- Wandbefestigung - Installation sur le mur - Montaje en pared - Montaggio a parete
∅ max. 4 mm (0.157“) ∅ min. 5 mm (0.196“)
~ 3 mm (0.118“)
Manufactured in China
Snom Technology GmbH
Wittestr. 30 G · 13509 Berlin · Germany
WALL MOUNT SLOT
DC 5V 800mA
Use only power supplies listed
in the user manual
WALL MOUNT SLOT
M110 SC
Manufactured in China
Snom Technology GmbH
Wittestr. 30 G · 13509 Berlin · Germany
WALL MOUNT SLOT
DC 5V 800mA
Use only power supplies listed
in the user manual
Removing the wall bracket - Entfernen der Wandhalterung - Retirer le support mural - Rimuovere la
staa a parete - Retire el soporto de pared
Connecting - Anschließen - Connecter - Collegare - Conectar
C
D
E
Network &
Power over Ethernet
Reset key
(1), (2)
(1)
If no PoE available
(2)
Not included in delivery
 Insert tab
in slot
 Insert tab
in slot
