アイテム 部品番号 名前 数量 UOM
1 302-0049 SwitchBatteryDisconnect 1 EA
2 3602-06 MetricHexNut 2 EA
3 3603-06 PlainWasher 29 EA
4 3603-08 PlainWasher 18 EA
5 3603-10 PlainWasher 16 EA
6 3604-05012 PanHeadScrew 2 EA
7 3605-06 SpringWasher 6 EA
8 3605-10 SpringWasher 7 EA
9 3606-06025 CountersunkSocketHeadScrew 1 EA
10 3610-06016 MetricBolt 9 EA
11 3610-06020 MetricBolt 2 EA
12 3610-06025 MetricBolt 2 EA
13 3610-08020 MetricBolt 1 EA
14 3610-08025 MetricBolt 8 EA
15 3610-10020 MetricBolt 4 EA
16 3610-10025 MetricBolt 2 EA
17 3610-10030 MetricBolt 1 EA
18 3610-10050 MetricBolt 3 EA
19 3611-05 MetricNylocNut 2 EA
20 3611-06 MetricNylocNut 10 EA
21 3611-08 MetricNylockNut 9 EA
22 3611-10 MetricNylocNut 6 EA
23 4381 Horn 1 EA
24 7025-008 JICMxUNORingNipple 1 EA
25 7031-009 JICMxUNORingMElbow 1 EA
26 8974 Screw,HammerDrive 4 EA
27 10268-1 BatteryBracketHA8023 1 EA
28 11596 Battery12VBVS70 1 EA
29 11679 CabinetDoor-Small 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Hydraulic Cabinet Assembly
Hydraulic Cabinet Assembly Wed Feb 24 00:49:12 UTC 2021 2-10
