アイテム 部品番号 名前 数量 UOM
30 11680 CabinetDoor-Large 1 EA
31 12716-13 CabinetTopPlate 1 EA
32 12716-14 CabinetSupport 1 EA
33 12833-4 SerialNumberPlate,NZ/AUS
Machines
1 EA
Not
Shown
0070901 SerialNumberPlate,US
Machines
1 EA
34 13164 CableTieMount-M10 1 EA
35 13811 LowerControlBoxAssembly 1 EA
36 13864 Cabinet 1 EA
37 13869-01 CabinetHinge,LH 2 EA
38 13869-02 CabinetHinge,RH 2 EA
39 13872 RubberChannelSection 1 EA
40 15123-01 MainManifoldAssembly 1 EA
41 15141-01 HydraulicTankAssembly 1 EA
42 60015-012 3/4"x1/4"NCBolt(Plated) 2 EA
43 60017-006 1"x3/8UNCBolt 3 EA
44 100434-015 HydFitting-90ElbowORFS(08)
-SAE(12)
2 EA
45 300840 LockOutLeverAssembly 1 EA
46 301440 AE-10OilFilter 1 EA
47 1431833 Bracket-PressureFilter 1 EA
48 3040269 BootCableEntryBlack1/0GA 2 EA
49 5560179 FlatWasher-Special 3 EA
50 6019325 PressureFilter 1 EA
51 8342416 LatchAdjustableTrigger,Key
508CH
1 EA
52 13781A StabiliserManifoldAssembly 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Hydraulic Cabinet Assembly
Hydraulic Cabinet Assembly Wed Feb 24 00:49:12 UTC 2021 2-10
