Page 2 - 20 UL25/UL32/UL40
TRANSPORTATION
Figure 2-13: Cylinder secured with retaining pin.
Figure 2-14: Lowering and raising with the tilt back handle.
Retaining pin
Cylinder
assembly
Hair pin retainer
Tilt back handle
Retaining pin
