6
Docking
Purchase two tents for easy docking.
*Please note: complete docking is not possible. The docking function does not prevent rainwater
from entering. Release the docking connection if rain is anticipated.
Connect the tents at the vestibules, the backrooms or the vestibule and the backroom (any
combination works). Secure the connection with the Velcro strap at two points on each
side, four points total.
1
A
A
B
B
C
C
D
D
Enter the room and stack the two front and side panels, then roll them up.
2
Cross the ropes with a ropetensioner, thensecure with apegandtighten tensioner.
3
Cross the ropes
Stack the two
panels and roll up.
D-ring
Pole
Pass the tape through the first D-ring.
Wrap around the two Poles.
Pass the tape through the other D-ring.
Secure with Velcro.
Velcro
