Snow Peak Entry Pack TT - Tarp Set-Up Procedure

Tarp Set-Up Procedure Make sure that two or more people take part in the set-up.
1
Hold the pole with two people and determine the position of the tarp in relation to the tent.
3
Set the pole and rope
next to the gromment
of the tarp and tape.
2
Forked
10m (32.8') Rope
Forked
10m (32.8') Rope
2m (6'6") Rope
2m (6'6") Rope
3m (9'8") Rope
3m (9'8") Rope
240cm
(7.8') Pole
Overlap
280cm
(9.1') Pole
Tarp
Tent
Long Short
Tent
Tarp
Grommet
Rope Tensioner
Tape
Tape
Secure
Tarp
Tarp
240cm
(7.8') Pole
Adjustment
Adjuster
280cm
(9.1') Pole
Forked
10m (32.8')
Rope
Forked 10m (32.8') Rope
B
C
A
Position the tarp so that it slightly overlaps with the vestibule of the tent, as shown in the figure
above. First, attach the 2m ropes and 3m ropes as in the figure A on the right, and then set up
following the steps below.
Spread the tarp next to the side of the tent, secure the connection
tape, and adjust the length of the tape with the adjuster so it slightly
overlaps with the vestibule of the tent. Install the adjuster facing the
ground, so it’s easier to adjust after installation.
7
Connection Tape
Overlap
Grommet
Grommet
Pole Position
B C
Pole Position
