SnowBlaster 56663 - Parts List

#56663 SNOW THROWER OPERATOR’S MANUAL 17
PARTS LIST
Part#
Stock#
Description
Part#
Stock#
Description
1
56663-001
Locknut M6
46
56663-046
Small Gear
2
56663-002
Washer 6
47
56663-047
Flat Key 3x12
3
56663-003
Right Fixing Plate
48
56663-048
Bearing 608-2Z
4
56663-004
TPU/Rubber Plate
49
56663-049
Gear Box
5
56663-005
Washer 6
50
56663-050
Bearing 6001-2Z
6
56663-006
Screw M6x16
51
56663-051
Screw ST4.2-65
7
56663-007
Left Fixing Plate
52
56663-052
Lower Motor Housing
8
56663-008
Screw M6x16
53
56663-053
Impeller
9
56663-009
Bearing 6202-2Z
54
56663-054
Stator
10
56663-010
Keep Plate
55
56663-055
Rotor
11
56663-011
Shaft Assembly
56
56663-056
Upper Motor Housing
12
56663-012
Small TPU/Rubber Plate
57
56663-057
Brush Holder
13
56663-013
Screw ST4.2x13
58
56663-058
Carbon Brush
14
56663-014
Right Cover
59
56663-059
Keep Plate
15
56663-015
Screw M5x12
60
56663-060
Screw ST3.2x9.5
16
56663-016
Snap Ring 15
61
56663-061
Shock Pad
17
56663-017
Bearing Housing
62
56663-062
Motor Keeper
18
56663-018
Right Collision Strip
63
56663-063
Screw ST4.2x16
19
56663-019
Main Housing
64
56663-064
Idler Arm Assembly
20
56663-020
Tapping Screw ST4.2x22
65
56663-065
Extension Spring
21
56663-021
Scraper
66
56663-066
Washer 4
22
56663-022
Left Collision Strip
67
56663-067
Screw M4x12
23
56663-023
Big Pulley
68
56663-068
Flat Idler
24
56663-024
Belt PJ670
69
56663-069
Bearing 6000-2Z
25
56663-025
Locknut M8
70
56663-070
Washer 5
26
56663-026
Left Cover
71
56663-071
Fixing Seat
27
56663-027
Screw M6x30
72
56663-072
Main Cover
28
56663-028
Washer 10
73
56663-073
Lever Keeper
29
56663-029
Right Metal Support
74
56663-074
Chute Direction Control Gear
30
56663-030
Spacer
75
56663-075
Resistance Washer
31
56663-031
Roller
76
56663-076
Chute
32
56663-032
Roller Shaft
77
56663-077
Handle
33
56663-033
Cotton Pin 2x20
78
56663-078
Knob
34
56663-034
Left Metal Support
79
56663-079
Screw M8x25
35
56663-035
Screw M4x16
80
56663-080
Chute Deflector
36
56663-036
Screw ST4.2x40
81
56663-081
Blade
37
56663-037
Small Pulley
82
56663-082
Screw ST4.2x9.5
38
56663-038
Bearing Housing
83
56663-083
Lever
39
56663-039
Bearing 6201-2Z
84
56663-084
Connector
40
56663-040
Output Shaft
85
56663-085
Shaft
41
56663-041
Semicircular Key
86
56663-086
Cotton Pin 2x14
42
56663-042
Big Gear
87
56663-087
Rivet 4x20
43
56663-043
Snap Ring 10
88
56663-088
Lower Chute Crank
44
56663-044
Oil Seal
89
56663-089
Locknut M4
45
56663-045
Nut M8
90
56663-090
Screw M4x20
