Wet underoor heating wiring for single zone
N
SL
L
RT2 RT1
-
L
N
230V
MAINS
SUPPLY
UFH 2 port valve
SL
PL
BOILER
N
REMOTE FLOOR
PROBE
REMOTE AIR PROBE
