REGULAR MAINTENANCE
NAME
APPLICABLE MATERIAL
TYPE
QTY
Triangular blade
ironstainless steel
TCMT16T308
2pcs
Triangular blade
aluminium
TCGT16T304
2pcs
quadrilateral blade
Iron stainless steel
SCMT09T308
1pc
quadrilateral blade
aluminium
SCMT09T304
1pc
Precautions:
1.The power cable connection way is related with the direction of steering motor , and do not change
it without specially instruction.
2.Confirming the voltage is normal
3. Make sure the fuse meets the specification
4. The blade is replaceable blade, and replacing depend on different workpiece materials.
5.Blade Specifications
