INSTALLATION
CONNECTION
4
Follow indications when connecting the termi-
nal. Switch on voltage supply.
The DIRIS A40/A41 must be switched off
DIRIS 342 A
1
DIRIS 343 A
2
Fix the module in one of the four positions.
DIRIS 347 A
3
ThemoduleisttedontothebackoftheDIRIS A40/A41 in one of the 4 positions provided.
DIRIS 347 A
