socomec DIRIS A40 ETHERNET - Visual Diagnostic

DIRIS A40/A41 - RS485 - ETHERNET
®
6
DIRIS A40/A41 - Ref.: 536 181 B GB
VISUAL DIAGNOSTIC
INSTALLATION
LED Colour Status Description
SYS - NOT LIT No internal electrical supply
Firmware is re-initialising
Hardware is faulty
Yellow LIT Loadingphaseofthesoftware,
waiting to start
FLASHING AT 1Hz Error during the start-up phase
Green LIT Operating system functioning
COM Red NOT LIT No errors
FLASHING Not used
LIT Internal JBUS error
Green NOT LIT See red LED
FLASHING JBUS external error
LIT Noerror,fullyfunctional
Link Green NOT LIT No connection to the Ethernet network
LIT Ethernet Network connected
Activity Yellow FLASHING Sending/receiving Ethernet frames
> LED indicators
