socomec MDO 1600 TS - Page 9

2.2 Technical features MDO 1600 TS
Technical features
unit of
measurement
Value
Energy per stroke J
3700
Maximum Frequency s/min
490 - 670
Maximum oil flow l/min
170 - 190
Maximum working pressure bar
140
Maximum exhaust back pressure bar
10
Accumulator charging pressure bar
35
Calibration pressure of the hydraulic system maximum valve bar
180
Hammer weight in working conditions Kg
1650
Tool weight Kg
104
Pin retainer tool weight Kg
6,5
Pressure line pipe diameter (EN 856 - 4SP) G
1"
Return line pipe diameter (EN 853 - 2SN) G
1”1/4
Tool diameter mm
130
Hammer height with tool without adapting plate mm
2345
Maximum length of the tool inner guide (L) mm
479
Maximum diameter in front and back the tool bushings mm
135
Maximum oil temperature in the tank °C
80
Maximum absorbed power Kw
40
Excavator weight t
19 - 25
TECHNICAL FEATURES
9
