SUNSYS H30-H30i - Ref.: IOMSUNHMXX04-GB 00

2. PRODUCT DESCRIPTION

2.3.1. LCD display and buttons

2.3. Introduction to operation

The external features of the inverter are illustrated in figure 2.3-1 and the corresponding detailed description is provided in sub-

paragraphs 2.3-1 to 2.3-2.

2.3-1

External inverter features

2.3.1-1

System status information

LCD display

capacitive keypad

LEDS status

DC connectors

Data plate

Cover

AC connector

Earth connection (PE)

Removable panel

LEDS STATUS

GREEN YELLOW RED

SELECT

select page

EXIT

exit menu

ENTER

select menu or

confirm

LCD display
