9.7 Log chart
LOGNAME
LOG
NUMBER
VALUES DESCRIPTION FUNCTION
APPWORKMODE
1 0 CPC (CONSTANT PRESSURE) READ(04)/WRITE(06)
1 1 CFC (CONSTANT FLOW RATE) READ(04)/WRITE(06)
1 2 MIN/MAX READ(04)/WRITE(06)
CPCUNITSOFMEASURE
2
0……..X Pa, mbar, m3/h… READ(04)/WRITE(06)
CFCUNITSOFMEASURE
3
0……..X Pa, mbar, m3/h… READ(04)/WRITE(06)
PRESSURE
4
0……..X real sensor reading READ(04)
FLOWRATE
5
0……..X real flow rate reading READ(04)
PRESSUREREF1
6
0……..X SETPOINT PRESSURE REF 1 READ(04)/WRITE(06)
PRESSUREREF2
7
0……..X SETPOINT PRESSURE REF 2 READ(04)/WRITE(06)
MAXFLOWRATE.
8
1….30000 MAXIMUM FAN FLOW RATE READ(04)/WRITE(06)
REF.FLOWRATE
9
1….30000 SETPOINT FLOW RATE READ(04)/WRITE(06)
MIN.VALUE
10
0-->100 % MIN. MOTOR SETPOINT OUTPUT VALUE READ(04)/WRITE(06)
MAX.VALUE
11
0-->100 % MIN. MOTOR SETPOINT OUTPUT VALUE READ(04)/WRITE(06)
TACHOMETERVALUE
12
0……..X Motor value in Hz READ(04)
CPCPVALUE
13
0……..X PROPORTIONAL GAIN VALUE READ(04)(04)/WRITE(06)
CPCIVALUE
14
0……..X INTEGRATION VALUE READ(04)/WRITE(06)
CFCPVALUE
15
0……..X PROPORTIONAL GAIN VALUE READ(04)/WRITE(06)
CFCIVALUE
16
0……..X INTEGRATION VALUE READ(04)/WRITE(06)
KVALUE
17
0……..X FAN K FACTOR READ(04)/WRITE(06)
FIRMWAREVERSION
18
0……..X FIRMWARE INSTALLED IN CONTROLLER READ(04)
DATEOFMANUFACTURE
19
0……..X DATE OF MANUFACTURE READ(04)
ALARMS
20 0 NO ALARMS READ(04)
20 1 REGULATOR ALARM READ(04)
20 2 REF: ALARM READ(04)
20 3 OVERPRESSURE ALARM READ(04)
20 4 MODBUS ALARM READ(04)
RESETALARMS
0 -- WRITE(06)
21 1 RESET ACTIVATED ALARMS WRITE(06)
SWITCH4FUNCTION
22 0 RESET ACTIVATED ALARMS READ(04)/WRITE(06)
22 1 AUTOZERO READ(04)/WRITE(06)
22 2 GO STATUS READ(04)/WRITE(06)
MOTORSETPOINTVALUE
23
0……..X % MOTOR CONTROL OUTPUT VALUE 0--100% READ(04)
LANGUAGE
24 0 SPANISH READ(04)/WRITE(06)
24 1 ENGLISH READ(04)/WRITE(06)
2 - RESERVE- READ(04)/WRITE(06)
3 - RESERVE- READ(04)/WRITE(06)
4 - RESERVE- READ(04)/WRITE(06)
5 - RESERVE- READ(04)/WRITE(06)
6 - RESERVE- READ(04)/WRITE(06)
7 - RESERVE- READ(04)/WRITE(06)
8 - RESERVE- READ(04)/WRITE(06)
9 - RESERVE- READ(04)/WRITE(06)
RESTOREFACTORY
25 0 - - - - WRITE(06)
25 1 RESET FACTORY VALUES WRITE(06)
REGULATORALARM
26 0 TACHO READ(04)/WRITE(06)
26 1 VSD READ(04)/WRITE(06)
26 2 DEACTIVATE READ(04)/WRITE(06)
REF.ALARM
27 0 ACTIVATE READ(04)/WRITE(06)
27 1 DEACTIVATE READ(04)/WRITE(06)
OVERPRESSUREALARM
28 0 ACTIVATE READ(04)/WRITE(06)
28 1 DEACTIVATE READ(04)/WRITE(06)
MODBUSALARM
29 0 ACTIVATE READ(04)/WRITE(06)
29 1 DEACTIVATE READ(04)/WRITE(06)
MODBUSID
30
1 --> 257 DEVICE ID READ(04)/WRITE(06)
BAUDRATE
31 0 9600 READ(04)/WRITE(06)
31 1 19200 READ(04)/WRITE(06)
31 2 38400 READ(04)/WRITE(06)
DATABITS
32 0 7 BITS READ(04)/WRITE(06)
32 1 8 BITS READ(04)/WRITE(06)
PARITYBIT
33 0 NON READ(04)/WRITE(06)
33 1 EVEN READ(04)/WRITE(06)
33 2 ODD READ(04)/WRITE(06)
STOPBITS
34 0 0 READ(04)/WRITE(06)
34 1 1 READ(04)/WRITE(06)
34 2 2 READ(04)/WRITE(06)
READ(04)TIMEOUT
35
1 --> 2000 TIMEOUT TIME IN ms READ(04)/WRITE(06)
