SODECA WALL/DUCT - Page 4

Model
Speed
Maximumadmissible
current(A)
Power
installed
Tiltingangle
blades
Airflow
maximum
Sound
pressurelevel
Approx.
weight
According
toErp*
(r/min) 230V 400V 690V (kW) (º) (m
3
/h) dB(A) (kg)

THT/WALL‐90‐6T‐4IE3 970 13,50 7,80  3,00 30 39055 76 221 2020
THT/WALL‐100‐4T‐10IE3 1460  17,70 10,20 7,50 16 57650 90 239 2020
THT/WALL‐100‐4T‐15IE3 1460  22,00 12,70 11,00 22 66505 91 292 2020
THT/WALL‐100‐4T‐20IE3 1460  29,00 16,70 15,00 28 76445 92 307 2020
THT/WALL‐100‐6T‐5.5IE3 970  11,00 6,40 4,00 26 47955 81 239 2020
THT/WALL‐100‐6T‐7.5IE3 970  12,40 7,20 5,50 32 53545 82 276 2020
THT/WALL‐125‐4T/6‐20IE3 1470  29,87 17,25 15,00 10 78608 99 462 2020
THT/WALL‐125‐4T/6‐25IE3 1470  34,86 20,12 18,50 14 92546 100 530 2020
THT/WALL‐125‐4T/6‐30IE3 1470  41,77 24,11 22,00 16 98830 101 544 2020
THT/WALL‐125‐4T/6‐40IE3 1475  55,19 31,87 30,00 22 117456 101 625 2020
THT/WALL‐125‐4T/6‐50IE3 1480  73,00 42,10 37,00 26 131064 102 673 2020
THT/WALL‐125‐4T/9‐25IE3 1470  34,86 20,12 18,50 10 79671 95 539 2020
THT/WALL‐125‐4T/9‐30IE3 1470  41,77 24,11 22,00 12 88281 96 553 2020
THT/WALL‐125‐4T/9‐40IE3 1475  55,19 31,87 30,00 16 104040 96 634 2020
THT/WALL‐125‐4T/9‐50IE3 1480  73,00 42,10 37,00 20 118399 97 682 2020
THT/WALL‐125‐4T/12‐30IE3 1475  42,20 24,44 22,00 10 62897 99 569 2015
THT/WALL‐125‐4T/12‐40IE3 1470  53,30 31,02 30,00 14 79181 100 650 2015
THT/WALL‐125‐4T/12‐50IE3 1480  66,40 38,26 37,00 18 95715 100 693 2020
THT/WALL‐125‐6T/6‐5.5IE3 960  9,61 5,55 4,00 10 51502 82 395 2020
THT/WALL‐125‐6T/6‐7.5IE3 960  12,82 7,40 5,50 14 60634 83 402 2020
THT/WALL‐125‐6T/6‐10IE3 960  17,24 9,95 7,50 20 72647 83 427 2020
THT/WALL‐125‐6T/6‐15IE3 955  22,10 12,76 11,00 26 85869 84 457 2020
THT/WALL‐125‐6T/6‐20IE3 970  29,44 16,99 15,00 30 92854 85 530 2020
THT/WALL‐125‐6T/9‐10IE3 960  17,24 9,95 7,50 14 63487 84 436 2020
THT/WALL‐125‐6T/9‐15IE3 955  22,10 12,76 11,00 20 77572 85 466 2020
THT/WALL‐125‐6T/9‐20IE3 970  29,44 16,99 15,00 26 92968 86 539 2020
THT/WALL‐125‐6T/9‐25IE3 975  36,10 20,77 18,50 32 96500 87 569 2020
THT/WALL‐125‐6T/12‐25IE3 975  36,10 20,77 18,50 28 131859 84 579 2020
THT/WALL‐125‐6T/12‐30IE3 975  42,30 24,35 22,00 32 146765 85 621 2020
THT/WALL‐125‐6T/12‐40IE3 980  55,80 32,13 30,00 38 166138 86 739 2020
* According to ErP 2020 draft
Fig. 6
WALL/DUCT
Model
Speed
Maximumadmissible
current(A)
Power
installed
Airflow
maximum
Sound
pressurelevel
Approx.
weight
According
toErp*
(r/min) 230V 400V 690V (kW) (m
3
/h) dB(A) (kg)
WALL/DUCT‐40‐2T‐1.5IE3 2830 4,03 2,34  1,10 8800 84 55 2015
WALL/DUCT‐45‐2T‐2IE3 2875 5,34 3,07  1,50 10650 86 64 2015
WALL/DUCT‐45‐2T‐3IE3 2910 7,32 4,21  2,20 12750 88 68 2015
WALL/DUCT‐45‐4T‐0.5 1370 2,02 1,17  0,37 7100 68 53 2015
WALL/DUCT‐50‐4T‐0.75 1380 2,92 1,69  0,55 10400 70 63 2015
WALL/DUCT‐56‐4T‐1IE3 1420 2,82 1,62  0,75 12950 73 71 2020
WALL/DUCT‐56‐4T‐1.5IE3 1455 4,07 2,34  1,10 14000 74 77 2020
WALL/DUCT‐56‐4T‐2IE3 1440 5,41 3,11  1,50 15300 75 83 2015
WALL/DUCT‐56‐6T‐0.75 900 2,99 1,73  0,55 10000 62 70 2020
WALL/DUCT‐63‐4T‐1IE3 1420 2,82 1,62  0,75 14150 73 98 2020
