SODECA WALL/DUCT - Page 6

Model
Speed
Maximumadmissible
current(A)
Power
installed
Airflow
maximum
Sound
pressurelevel
Approx.
weight
According
toErp*
(r/min) 230V 400V 690V (kW) (m
3
/h) dB(A) (kg)
WALL/DUCT‐125‐6T/6‐20IE3 970  29,44 16,99 15,00 92854 85 530 2020
WALL/DUCT‐125‐6T/9‐10IE3 960  17,24 9,95 7,50 63487 84 436 2020
WALL/DUCT‐125‐6T/9‐15IE3 955  22,10 12,76 11,00 77572 85 466 2020
WALL/DUCT‐125‐6T/9‐20IE3 970  29,44 16,99 15,00 92968 86 539 2020
WALL/DUCT‐125‐6T/9‐25IE3 975  36,10 20,77 18,50 96500 87 569 2020
WALL/DUCT‐125‐6T/12‐25IE3 975  36,10 20,77 18,50 131859 84 579 2020
WALL/DUCT‐125‐6T/12‐30IE3 975  42,30 24,35 22,00 146765 85 621 2020
WALL/DUCT‐125‐6T/12‐40IE3 980  55,80 32,13 30,00 166138 86 739 2020
* According to ErP 2020 draft
