USER GUIDE ST32BV
1- GETTING ST32BV OUT OF THE PACKING
RIGHT SIDE POD
SUPPORT
RIGHT SIDE POD
SPOILER
ST32BV FRAME
FUEL TANK
SEAT
LEFT SIDE POD
NASSEAU PANEL
LEFT SIDE POD
SUPPORT
STEERING COLUMN
ASSEMBLY
STEERING WHEEL
OVERFLOW
BOTTLE
GEAR LEVER
ASSEMBLY
RIMS
REAR BUMPER
STUB AXLE SCREW
A
DJUSTER
STUB AXLE
SPACER ADJU
STER
SLOTTED WRENCH
NOTE :
Prior to assembling your kart, check the above described elements and familiarize yourself
with them.
THE PART NUMBERS OF THE VARIOUS ITEMS CAN BE FOUND IN THE “SPARE PARTS
CATALOGUE“.
- 4 –
EDITION : JANUARY 2010 MAN038.011
