USER GUIDE ST32BV
4.4 TIGHTENING THE PLASTIC STEERING COLUMN SUPPORT.
- 8 –
After compl
eting the above steps :
 Tighten the screw (8).
8
4.5 ASSEMBLY OF THE STEERING WHEEL.
 Tighten the steering wheel (1) with the 3 screws, on the steering wheel support (2).
 Tighten the steering wheel support on the steering column.
Check:
once the steering system is assembled, please check that the steering wheel is free to
make a quarter of a turn right and left.
 A bad assembly or a bad adjustment of the steering system can lead to accidents.
Systematically check the tightening of the system and its adjustment.
STRAIGHT PART
FORWARD
2
1
EDITION : JANUARY 2010 MAN038.011
