www.soehnle-professional.com
1.6 Technical data
> Large LCD display, digit height: 20 mm, non-approvable
> Internal user calibration with switching between kg and lb
> Materials:
Display housing: plastic
> Integrated battery with charge adapter 100–240 V/ 50–60 Hz, capacity: 50 h,
charging time: 5.5 h
> Weighing ranges: 15 kg, 30 kg, 60 kg, 150 kg, 200 kg, 3,000 kg
> Protection class IP 42
> Nominal operating temperature: -10°C to 40°C
> Storage temperature: -10°C to 55°C
1.7 Startup
Connect the power adapter to the scales.
Ensure that there is clear access to the power socket.
Before the initial start-up of the scales, the battery must first be charged for 5 hours!
1.8 Switching On/Off
Switch the scales on and off using ON/TARA/OFF button.
The scales should not be loaded when doing so.
Important: Place the weighed items on the scales carefully. Do not keep the platform
continuously loaded. Avoid impacts and loads above the specified weighing range, as these
could damage the scales.
