Shenzhen SOFARSOLAR CO., Ltd.

Solar Grid-tied Inverter

Product Model: SOFAR 1.1K-3.3KTL-G3

User manual

Table of Contents

Questions and Answers

S
Shane HarmonAug 17, 2025
What to do if Sofarsolar SOFAR 1100TL-G3 shows power grid voltage too high?
- D
  donald07Aug 18, 2025
  If the alarm occurs occasionally, the issue might be temporary grid fluctuations; the inverter should return to normal when the grid stabilizes. However, if this happens frequently, verify that your grid voltage and frequency are within the acceptable range. If they are not, contact technical support. If the voltage and frequency are normal, inspect the AC circuit breaker and AC wiring. If problems persist despite correct voltage/frequency and wiring, contact technical support to adjust the inverter's protection settings after getting approval from your local grid operator.
M
Matthew HallAug 20, 2025
What to do if Sofarsolar SOFAR 1100TL-G3 Inverter shows GFCI fault?
- A
  Ashley VaughanAug 20, 2025
  If the GFCI fault occurs occasionally, it might be due to temporary external circuit abnormalities, and the inverter should automatically return to normal once the issue is resolved. However, if the fault occurs frequently and lasts a long time, check the insulation resistance between the PV array and earth (ground) to ensure it is not too low. Also, inspect the insulation of the PV cables.
S
Samuel MitchellAug 22, 2025
Why is my Sofarsolar SOFAR 1100TL-G3 Inverter temp too high?
- E
  Ernest EscobarAug 23, 2025
  The inverter temperature might be too high because the ambient temperature of its installation location exceeds the upper limit. To resolve this, improve ventilation around the inverter to decrease the temperature.
P
Philip GarciaAug 25, 2025
What to do if Sofarsolar Inverter showing input voltage too high?
- C
  Chloe ContrerasAug 26, 2025
  The input voltage might be too high because too many PV modules are connected in series in a PV string, causing the voltage (Voc) of the PV string to exceed the inverter's maximum input voltage. To fix this, adjust the number of PV modules connected in series to decrease the voltage of the PV string, ensuring it fits within the inverter's input voltage range. The inverter should automatically return to normal operation after these adjustments.
A
Autumn SmithAug 27, 2025
Why Sofarsolar SOFAR 1100TL-G3 showing input voltage too low?
- O
  Olivia HolmesAug 27, 2025
  The input voltage might be too low because too few PV modules are connected in series in a PV string. This results in the voltage (Vmp) of the PV string being lower than the inverter's minimum operating voltage. To resolve this, adjust the number of series-connected PV modules to increase the voltage of the PV string, ensuring it fits within the inverter's input voltage range. The inverter will automatically return to normal operation after the correct adjustments.
X
xhunterAug 30, 2025
What to do if Sofarsolar SOFAR 1100TL-G3 Inverter grid current is too high and hardware protection activated?
- G
  gregorybrowningAug 30, 2025
  ID15-ID24 indicate internal faults within the inverter. Turn OFF the DC switch, wait for 5 minutes, and then turn it back ON. Check if the fault is rectified. If the issue persists, contact technical support.
P
Penny EspinozaSep 1, 2025
Why Sofarsolar SOFAR 1100TL-G3 derated because of high temperature?
- L
  Luke WagnerSep 2, 2025
  The inverter may have derated because the ambient temperature of its installation position exceeds the upper limit. To solve this, improve ventilation to decrease the temperature around the inverter.
D
Deborah MurphySep 4, 2025
What to do if Sofarsolar Inverter input current is too high?
- Y
  yhartSep 4, 2025
  Check if the input current exceeds the maximum input current of the inverter. Also, verify the input wiring. If both are correct and the issue persists, contact technical support.
J
juan29Sep 6, 2025
Why Sofarsolar SOFAR 1100TL-G3 bus voltage is too low?
- S
  Sarah NicholsSep 7, 2025
  If the PV array configuration is correct (no ID05 fault), the bus voltage might be too low because the solar irradiance is insufficient. The inverter should automatically return to normal operation once the solar irradiance returns to a normal level.
E
emily69Sep 9, 2025
What to do if Sofarsolar SOFAR 1100TL-G3 input current is not balanced?
- N
  Nathan ChaneySep 9, 2025
  Check the input mode setting (parallel mode/independent mode) of the inverter. If it’s incorrect, change it according to the manual.

Summary

Basic Safety Information

General Safety Instructions

Crucial safety guidelines for installation and operation.

Qualified Personnel Requirements

Specifies who is authorized to install and maintain the inverter.

Electrical Connection Safety

Critical safety warnings and procedures for electrical connections.

Operation Safety Precautions

Safety precautions to be observed during inverter operation.

Maintenance and Repair Safety

Safety procedures and warnings for inverter maintenance and repair.

Installation Guide

Determining the Installation Position

Physical Inverter Installation Steps

Electrical Connections

General Electrical Connection Notes

Important safety notes and requirements before making electrical connections.

Connecting PGND Cables (Grounding)

Procedures for properly connecting the ground (PGND) cables for safety.

Connecting DC Input Power Cables

Step-by-step instructions for connecting DC power input cables to the inverter.

Connecting AC Output Power Cables

Detailed guide for connecting AC output power cables, including breaker and connector types.

RS485, CT, and Logic Interface Connections

Instructions for connecting communication interfaces and logic signals.

Communication Methods Overview

PC Communication via Wi-Fi;GPRS;Ethernet

Commissioning of Inverter

Safety Inspection Before Commissioning

Essential checks to ensure safety before starting the inverter.

Starting the Inverter

Steps to safely power on and start the inverter operation.

Inverter Shutdown Procedure

Instructions for safely turning off and shutting down the inverter.

Operation Interface

Standard Interface Screens

Main Interface and Settings Navigation

Navigating the main menu and accessing various setting options.

Enter Setting Interface

Software Update Procedure

Steps for updating the inverter's firmware via USB flash drive.

Troubleshooting and Maintenance

Troubleshooting Guide

Comprehensive guide to identify and resolve common inverter faults and errors.

Maintenance Procedures

Technical Data

Sofarsolar SOFAR 1100TL-G3 Specifications

General

Model	SOFAR 1100TL-G3
Rated Power	1100 W
Max. DC Voltage	550 V
Max. Input Voltage	550 V
Start Voltage	80 V
Number of MPP Trackers	1
Max. Input Current	12 A
Rated AC Power	1100 W
Nominal AC Voltage	230 V
Rated Output Voltage	230 V
AC Voltage Range	180 V - 280 V
Nominal Frequency	50 Hz / 60 Hz
Output Frequency	50 Hz / 60 Hz
THDi	<3%
MPPT Efficiency	99.9%
DC Connection	MC4
AC Connection	Plug
Protection Degree	IP65
Protection Level	II
Topology	Transformerless
Cooling	Natural convection
Cooling Method	Natural Convection
Noise Emission	<25 dB
MPPT Voltage Range	80V-550V
Power Factor	>0.99
Operating Temperature Range	-25 °C to +60 °C
Relative Humidity	0-100%
Operating Temperature	-25 ~ +60 °C
