SOFAR 1.1K~3.3KTL-G3 User manual
Copyright © Shenzhen SOFARSOLAR Co., Ltd
A1
：Waterproof stopper
Step3 Select appropriate cable according Table4-2,remove the insulation layer
using a wire stripper, the length of the wire core is about 6mm,insert the cable
through the cable gland and waterproof cover, according to Table4-4,connect the
wires as per the labels, and secure the wire using a slotted screwdriver.as shown in
the figure below:
Table 4-4 Function description of the communication terminals
Figure 4-27
