Software House PSX-GCM-RB User Manual

13
Specifications
Section 4 – Specifications
4.1 Electrical Specifications - continued
Specifications PSX-ISUSE 150W PSX-ISUSE 250W
AC Input Voltage 120/230VAC
±15% at 50-60Hz
120/230VAC
±15% at 50-60Hz
Power 200 Watts 300 Watts
Standby Current 100mA 100mA
Rated Current for UL603 Proprietary
Alarm Installations
Current 2.5A maximum from
all circuits in system
2.5A maximum from
all circuits in system
DC Output at 12V Setting Voltage 12.5V ±0.5V nominal 12.5V ±0.5V nominal
Max Current 12A 20A
Ripple 120mV 120mV
Regulation ±2% ±2%
Efficiency 88% (120VAC
60Hz In, Full Load,
No Batt)
89% (120VAC
60Hz In, Full Load,
No Batt)
DC Output at 24V Setting Voltage 25.0V ±0.5V nominal 25.0V ±0.5V nominal
Max Current 6A 10A
Ripple 120mV 120mV
Regulation ±2% ±2%
Efficiency 88% (120VAC
60Hz In, Full Load,
No Batt)
89% (120VAC
60Hz In, Full Load,
No Batt)
Battery Size & Type 4-80AH Lead Acid
or Gel Cell
4-80AH Lead Acid
or Gel Cell
Charge Current 2A (±10%) Maximum
(Adjustable via
PowerCom Software)
2A (±10%) Maximum
(Adjustable via
PowerCom Software)
Fuse Ratings DC1 (Internal) ATM 15A ATM 30A
DC2 (Internal) ATM 15A ATM 30A
Battery (Internal) ATM 15A ATM 30A
BTU Output BTU 66 109
Fault Setpoints Low AC 95V (±6%) 95V (±6%)
Earth GND 2000 Ohms 2000 Ohms
Output Voltage ±10% of Nominal ±10% of Nominal
Batt Voltage ±10% of Nominal ±10% of Nominal
Batt Presence 6–15V (12V Setting),
11–29V (24V Setting)
6–15V (12V Setting),
11–29V (24V Setting)
Fault Relay Contacts AC FLT 1A at 24VDC 1A at 24VDC
SYS FLT 1A at 24VDC 1A at 24VDC
Distributed Outputs
Count 16
Current Fused 3A
Current PTC 2.5A
