11
Solar-Log™ PRO380 Mod
Solar-Log™ PRO380 Mod
Cable connection via S0 (consumption):
Solar-Log™ S
0
terminal block Solar-Log™ PRO380 Mod
Pin assignment Pin assignment
1 - S0+ 18 - S0+
2 - S0- 19 - S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Possible meter operating modes for the Solar-Log™ PRO380 Mod via SO connection (consumption):
•
Meter for the entire plant
•
Sub-consumption meter
•
Consumption meter
•
Inverter mode
