Solar-Log 2000 Connection Manual

5
Solar-Log™ Meter Operating Modes
Explanation of the Solar-Log™ Meter Operating Modes
2 Solar-Log™ Meter Operating Modes
2.1 Explanation of the Solar-Log™ Meter Operating Modes
There are various setting options when configuring meters in Solar-Log™. These are in particular:
•
Battery meter (bi-directional meter):
• Records the battery charges and discharges.
•
Deactivated: The recording of consumption has been or is deactivated.
•
Meter for the entire plant: The entire production from all of the inverters.
•
Sub-consumer: Meter to record the individual consumption from appliances that was already
recorded with a consumption meter.
•
Utility Meter (U+I) (only Solar-Log 2000): Meter for control and reduction functions - including
current measurements if necessary with current transformers.
•
Utility Meter (U) (only Solar-Log 2000): Meter for control and reduction functions - only voltage
measurements.
•
Consumption meter: Meter that only records the consumption.
•
Consumption meter (Bi-directional meter): Meter that records consumption and production collec-
tively - the actual consumption is determined by monitoring the inverters.
•
Inverter mode: The meter values are considered inverter values.

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
