Solar-Log 2000 Connection Manual

16
Iskra
Iskra WS0021
6 Iskra
6.1 Iskra WS0021
Selections available under Iskra
Overview
•
2-pin wiring
•
Installation steps
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™.
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via S0:
Solar-Log™ S
0
terminal block Iskra WS0021
Pin assignment Pin assignment
1 - S0+ 9 - S0+
2 - S0- 8 - S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Possible meter operating modes for the Iskra WS0021 meter via S0:
•
Meter for the entire plant
•
Sub-consumption meter
•
Consumption meter
•
Inverter mode

Solar-Log 2000 Specifications

General

Device Type	Data Logger
Max Inverters	100
Power Supply	24 V DC
Remote Monitoring	Yes
Ethernet interface	Yes
Communication Interfaces	RS485, Ethernet
Protocols	Modbus
Data Storage	Internal
