Take the 555Wp PV module as an example. After considering above two parameters, the recommended
module configurations are listed in the table below.
(reference)
- 555Wp
- Imp: 17.32A
- Voc: 38.46Vdc
- Isc: 18.33A
- Cells: 110
SOLAR INPUT 1 SOLAR INPUT 2
Q'ty of
panels
Total Input
Power
Min in series: 3pcs, per input
Max. in series: 10pcs, per input
3pcs in series x 3pcs 1665W
x 3pcs in series 3pcs 1665W
7pcs in series x 7pcs 3885W
x 7pcs in series 7pcs 3885W
7pcs in series 7pcs in series 14pcs 7770W
