3. INTRODUCTION
Read this user manual completely before using the device. In the appendices you will find the
technical specifications of the pure sine wave power inverters.
This DC-AC inverter converts a 12 or a 24 Volts DC voltage into a AC voltage with a pure sine
wave (100-127V/220-240VAC). With this device it is possible, with use of the right battery, to
supply equipment that normally requires a mains supply.
Important
Always check the actual power rating of the equipment (power consumption). In addition, bear
in mind the surge powers. These (start-up) peaks can be as much as 5-7 times the continuous
power consumption. Check whether these values are within the capacity limits of the inverter.
Equipment with high surge power are for example: air conditioning, vacuum cleaner, tools and
pumps. If you want to use multiple equipment at the same time, then add up the power
consumption.
4. INSTALLATION
4.1 Mounting
The inverter must be mounted in a space that complies with the following:
-
Mount the inverter in a dry place where there is no chance of it being affected by moisture or
dirt. Also be aware of moisture or dirt that can be sucked in by the fan.
-
Leave enough space on all sides of the inverter (min. 10cm) for air circulation. Make sure that
there are ventilation vents.
-
The ambient temperature must be between 0ºC and 40ºC. Ideal is between 15ºC and 25ºC.
-
Keep the inverter out of the reach of children.
-
A working inverter produces a dangerous voltage.
-
Do not use the inverter in places where gases are released or flammable materials are stored.
