14E20 / E25 ELLIPTICAL
#120. M5 x 15mm
Phillips Head Screw
(15 pcs)
#122. Ø3.5 x 12mm
Sheet Metal Screw
(8 pcs)
#100. Switch Wire Cap
(2 pcs)
E25 ASSEMBLY INSTRUCTIONS
1. Connect Swing Arm Wire (Lower), Resistance/Incline (50) , Swing Arm Wire
(Upper), Incline (49) and connect Swing Arm Wire (Lower), Resistance/Incline
(50) , Swing Arm Wire (Upper), Resistance (48). Push the excessive wires into
the Console Mast and plug in the Switch Wire Cap (100) at each side on the
Mast .
2. Attach front (89) and rear (90) Handle Bar Covers together on left Swing Arm
shaft and secure using two Sheet Metal Screws (122) and the Phillips Head
Screw Driver (150). Repeat this process for the right side Handle Bar Covers
(91) and (92).
3. Secure the Connecting Arm Covers (170-L & 171-R) on the Left and Right
Connecting Arms with four Phillips Head Screws (120) and two Sheet Metal
Screws (122) using the Combination M5 Allen Wrench & Phillips Head Screw
Driver (149).
4. Secure Left Slide Wheel Cover (87) on Left Pedal Arm with two Phillips Head
Screw (120) by using Phillips Head Screw Driver (150). Repeat this process for
the Right Slide Wheel Cover (88).
5. Secure Console Chin Cover (Front) (93) on the Mast and then match with
Console Chin Cover (Rear) (94). Secure the covers with three Phillips Head
Screws (120), two Sheet Metal Screws (122) and the Phillips Head Screw
Driver (150).
6. Install the Incline Bottom Cover (165) on the Main Frame (1) with two Phillips
Head Screws (120) by using Phillips Head Screw Driver (150).
7. Install the Front Stabilizer Cover (166) on the Front Stabilizer Bar (2) with two
Phillips Head Screws (120) by using Phillips Head Screw Driver (150).
8. Snap Rear Bar Cover (97) into the hole on the Incline Rail Assembly.
PLASTIC PARTS
4
HARDWARE STEP 4
1. Connect the Upper Swing Arm (L) (18) to the left Lower Swing Arm and
connect the Upper Swing Arm (R) (19) to the right Lower Swing Arm , and
secure them with six Hex Head Bolts (106), four Curved Washers (143) and six
Nyloc Nuts (129) by using the Wrenches (151 & 152).
UPPER SWING ARMS
3
HARDWARE STEP 3
See Page 15 for Illustration
See Page 15 for Illustration
#106. 5/16” x 1-3/4”
Hex Head Bolt (6 pcs)
#129. 5/16” x 7T
Nyloc Nut (6 pcs)
#143. 5/16” x 23mm
x 1.5T Curved Washer
(4 pcs)
To Next Page
