SOLE E20 - Page 8

6E20 / E25 ELLIPTICAL
HARDWARE STEP 2
2
#115. 5/16” x 15mm
Button Head Socket Bolt (2 pcs)
#104. 5/16” x 15mm
Hex Head Bolt (2 pcs)
HARDWARE STEP 3
3
#129. 5/16” x 7T
Nyloc Nut (6 pcs)
HARDWARE STEP 4 (E20)
4
#120. M5 x 15mm
Phillips Head Screw (4 pcs)
#122. Ø3.5 x 12mm
Sheet Metal Screw (6 pcs)
#138. Ø8.5 × 26mm × 2T
Flat Washer (4 pcs)
#106. 5/16” x 1-3/4”
Hex Head Bolt (6 pcs)
#143. 5/16” x 23mm x 1.5T
Curved Washer (4 pcs)
#100. Switch Wire Cap
(2 pcs)
HARDWARE STEP 4 (E25)
4
#120. M5 x 15mm
Phillips Head Screw (15 pcs)
#122. Ø3.5 x 12mm
Sheet Metal Screw (8 pcs)
