page 22 - Installing the collectors
Technical changes may be made without notice
Page 19 of 24
Installation
instructions
-
Wooden frame collectors
In
-
roof
installation
Bracket 7x40mm
1st Collector 2nd Collector 3rd Collector
4x80mm 4x40mm
Mounting installation: Horizontal installation - view from below
