Solfex IRC 2.1 - Commissioning Checklist & Warranty Form

Solar Collector Details
Manufacturers Name .......................................................... Model ........................................................
Evacuated Tube Yes No Flat Panel Yes No
Direct Flow
Heat Pipe On roof Roof Integrated
Gross collector area ...................M² Absorber Area...................M²
Collector Serial number ( s ) .
......................................................... (located on the collector)
Panel Orientation S SW SE E/W
Panel Angle ..........°
Stagnation Temperature .
......... °C
Cylinder Details
Manufacturers Name .......................................................... Model ........................................................
Vented Cylinders only
Capacity of cylinder..........................................................Litres
Is the vent pipe correctly installed? Yes
No
What is the static head in meters? ..........................................................
What is the cylinder thermostat setting? ..........°C
Unvented Cylinders only
Capacity of cylinder..........................................................Litres
What is the incoming water pressure.
.........................................................BAR
Has strainer been cleaned of installation debris ? Yes
No
Has a water treatment device been fitted? Yes No
If Yes to above what type..........................................................
Are T & P and expansion valves fitted and discharged tested? Yes No
Is Primary & solar energy cut out 2 port valves operational Yes No
Pressure reducing valve setting..........................................................BAR
Has expansion Vessel or internal air gap been checked? Yes
No
What is the cylinder thermostat setting? ..........°C
Has G3 requirements been fully achieved? Yes
No
SOLFEX system commissioning checklist
and warranty form
page 32 - System commissioning checklist and warranty form
