THERMOCUBE 200/300/400 THERMOELECTRIC CHILLER MANUAL 52-11300-1
SOLID STATE COOLING SYSTEMS, 167 MYERS CORNERS ROAD, WAPPINGERS FALLS, NY 12590 6
TELEPHONE: (845) 296-1300 FAX: (845) 296-1303 WEB: WWW.SSCOOLING.COM VERSION M28
Figure 1
ThermoCube 200/300/400 Cooling Capacity in 20°C Ambient (typical)
Figure 2
ThermoCube 200/300/400 Pump Performance @ 20°C (typical)
• 1C 1 lpm Centrifugal Pump
• 1CL 1 lpm Low Pres Centrifugal Pump
• 1D 1 lpm Diaphragm Pump • 1G 1 lpm Gear Pump
• 2D 2 lpm Diaphragm Pump • 2G 2 lpm Gear Pump
• 3D 3 lpm Diaphragm Pump • 3G 3 lpm Gear Pump
Note: ThermoCube 400 curve was
measured with 208 VAC input power
