SSL Live Installation Information
*7 - VGA Monitor
Connection to optional Overview monitor
Three-row 15-pin D-type DE-15 connector
Native resolution : 1280 x 1024 pixels
*8a - USB Connections
USB 2.0 spec. connections for optional keyboard, mouse or storage peripherals
Up to 500 mA
*8b - Power USB Connector
USB Power connection for tablets and USB powered devices
Up to 3 A
*8c - USB B Connection
USB B Connection. Connect to console via USB A-B cable
*9 - Dante
1 pair of Dante network connections.
Connector type: 2 x RJ45 for Primary and Secondary Connections.
*10 - Headphone Outputs
A pair of front panel mounted ¼” jack sockets for Headphones.
Headphone Output Pinout :
Sleeve Screen/Ground
Ring Right
Tip Left
*11 - 3.5 mm Jack Input
3.5 mm stereo jack socket for phones or portable media players.
*12 - Reserved
*13 - Wordclock
BNC connections to IEC 60169-8
75 Ω Characteristic Impedance, unterminated internally.
Wordclock Output is active when no Input is present. Wordclock Output follows console selected
reference source for use as a local Wordclock reference.
*14 - Connectivity Network Port
Connector type: RJ45
Cat 5e 10/100/1000 bit/s Ethernet Ports, used to connect remote devices to console (not Dante).
www.solidstatelogic.com Page 31 of 43
